8.2KW 10.2KW DC 220/230V AC Pure Sine Wave Solar Double MPPT On/Off Grid Solar Hybrid Inverter

Place of Origin China
Brand Name Sunpok Energy
Certification CE MSDS UN38.3
Model Number HYP4850U100-H
Minimum Order Quantity 1 Unit
Price USD 597 /Pcs
Packaging Details Carton
Delivery Time 5-10 Day
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Unit Per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Grid Solar Inverter Application Solar Power System
Inverter Type Off-grid Solar Power Inverter Protection Overload
Display LCD Display Rated Output Power 5,000W
Output Frequency 50Hz/60Hz Max.Peak Power 10,000VA
Output Waveform Pure Sine Wave Output Battery Type Lithium-ion
Efficiency >90% Working Temperature -20℃~+50℃
Output Voltage 230V Output Current 35.6A/44.3A
Highlight

8.2KW Solar Hybrid Inverter

,

10.2KW Solar Hybrid Inverter

,

220/230V Solar Hybrid Inverter

Leave a Message
Product Description

Sunpok Solarwechselrichter: Erhöhen Sie Ihre Energieunabhängigkeit

Nutzen Sie die Kraft der Sonne mit einem Sunpok-Solarwechselrichter – der Schlüssel zu einer effizienten, zuverlässigen und nachhaltigen Stromerzeugung für Ihr Zuhause oder Ihr Unternehmen.



Effiziente Energieumwandlung:
Sunpok-Solarwechselrichter sind darauf ausgelegt, die Energieumwandlung zu maximieren und sicherzustellen, dass jeder Sonnenstrahl effizient in nutzbaren Strom umgewandelt wird. Profitieren Sie von optimaler Leistung und Kosteneinsparungen mit unseren fortschrittlichen Wechselrichtern.



Zuverlässigkeit, auf die Sie zählen können:
Zuverlässigkeit ist bei Sunpok-Solarwechselrichtern Standard. Unsere Wechselrichter sind so konzipiert, dass sie den unterschiedlichsten Umgebungsbedingungen standhalten und eine stabile Ausgangsleistung liefern, sodass Sie auch in den kommenden Jahren beruhigt sein können.



Nahtlose Integration und einfache Nutzung:
Sunpok-Solarwechselrichter lassen sich nahtlos in neue oder bestehende Solarsysteme integrieren und ermöglichen eine sorgenfreie Installation und einen problemlosen Betrieb. Überwachen Sie ganz einfach Ihre Energieproduktion und Ihren Energieverbrauch mit einer benutzerfreundlichen Oberfläche und intelligenten Überwachungsfunktionen.



Eigenschaften des Sunpok-Solarwechselrichters:

Intelligente Überwachung: Durch die Echtzeitüberwachung können Sie den Solarverbrauch verfolgen und optimieren.
On-Grid- und Off-Grid-Fähigkeiten: Unsere Wechselrichter unterstützen sowohl On-Grid- als auch Off-Grid-Anwendungen und bieten Flexibilität entsprechend Ihrem Energiebedarf.


Fernüberwachung und -steuerung: Überwachen und steuern Sie Ihre Solaranlage bequem aus der Ferne über eine mobile App oder eine Weboberfläche.


Entdecken Sie die Vorteile von Sunpok:
Sind Sie bereit, die Kontrolle über Ihre Energiezukunft zu übernehmen? Entdecken Sie die Zuverlässigkeit und Effizienz eines Sunpok-Solarwechselrichters. Kontaktieren Sie uns noch heute, um mehr über unsere Solarlösungen zu erfahren und Ihre Reise zur Energieunabhängigkeit mit Sunpok zu beginnen.



8.2KW 10.2KW DC 220/230V AC Pure Sine Wave Solar Double MPPT On/Off Grid Solar Hybrid Inverter 0





SUNPOK Off-Grid Off-Grid Inverter



Sunpok 5Kw single-phase high-frequency off-grid inverter is suitable for areas without power, nomadic areas, communication base stations, areas with unstable power, islands, border posts, scenic management offices, newsstands, battery packs for battery manufacturers, etc. Equipped with LED display, supports USB/RS232/RS485/Bluetooth/Dry-contact, compact design, and high-cost performance.





Model HYP4850U100-H
INVERTER OUTPUT
Num. of MPPT Trackers 1
Max.PV Array Power 5,500W
Max.Input Current 22A
Max.Voltage of Open Circuit 500Vdc
MPPT Voltage Range MPPT Voltage Range
MAINS/GENERATOR INPUT
Input Voltage Range 90~140Vac
Frequency Range 50/60Hz
Bypass Overload Current 63A
EFFICIENCY
MPPT Tracking Efficiency 99.9%
99.9% >92%
GENERAL
Dimensions 446.9*350*133mm
Weight 13kg
Protection Degree IP20,indoor only
IP20,indoor only -15~55℃
Noise <60dB
Cooling Method Internal Fan
Warranty 2 years
COMMUNICATION
Embedded Interfaces RS485 / CAN / USB / Dry contact
External Modules(Optional) Wi-Fi / GPRS
CERTIFACATION
Safety CE(LEC62109-1)
EMC EN61000
Rohs Yes



8.2KW 10.2KW DC 220/230V AC Pure Sine Wave Solar Double MPPT On/Off Grid Solar Hybrid Inverter 1





Safety and Protection Features: Safety is a top priority with the HYP4850U100-H Off-Grid Inverter. It includes comprehensive protection features such as overload protection, over-temperature protection, and short-circuit protection. These safeguards ensure the longevity of the inverter and the safety of connected devices.



8.2KW 10.2KW DC 220/230V AC Pure Sine Wave Solar Double MPPT On/Off Grid Solar Hybrid Inverter 2



Features



Efficient power generation with higher income:



1.5 times overload output (200ms), resist the impact of instantaneous load



Wide voltage input range, early start and late stop, longer lasting power generation



Photovoltaic controller power upgrade can be connected to 5kW



MPPT has a wide voltage range and can adapt to various crystalline silicon components



Support mains bypass fast charging



Intelligent protection, simple operation, and maintenance:



Various gear charging voltages, adaptable to different batteries



Multiple working modes: photovoltaic priority/mains power priority/battery priority



LCD can be externally introduced to meet the monitoring needs of different customers



Non-linear loads can be connected



Safe and reliable, comprehensive peace of mind:



Diverse communication methods, support USB/RS232/RS485/Bluetooth/dry contact



Smart battery charger design to optimize battery performance



Mobile phone/computer intelligent monitoring, more convenient operation anytime and anywhere





FAQ

Question 1: What is the lead time?
Answer 1: We can deliver within 3-15 days.

Question 2: What is the warranty period, and how many years?
Answer 2: The warranty period for inverter is 2-5 years.

Question 3: How is your technical support?
Answer 3: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you a video call anytime, our engineer will also go to overseas help our customers if necessary.

Question 4: How to become your agent?
Answer 4: Contact us through the website, email, or phone, and we can talk about details to confirm.

Question 5: Is the sample available and free?
Answer 5: The sample will be charged a cost, but the cost will be refunded after the bulk order.

Question 6: Do you support OEM/ODM?
Answer 6: Of course, we can do customized services for our partners.

If you have other questions, please add the contact information of our sales manager to understand, thank you!
